Food Lyophilization Process made in China can be provided you with right price. Regulations-compliant SCADA control systems; energy-saving control systems for compressors and vacuum pumps. High-precision shelves: flatness ≤1.0mm, temperature uniformity ≤1℃. Supports system backup and automatic replacement (compressor, vacuum pump, circulation pump, etc.).
Since 2009, LYOMAC has been a manufacturer of Food Lyophilization Process for the pharmaceutical, biological and nutraceutical industries. With more than 15 years of experience, LYOMAC has delivered more than 300 systems to more than 20 countries, providing solutions according to the actual needs of the users, complying with cGMP, GAMP5 and FDA standards. Our industrial grade lyophilizers have a drying capacity of up to 1000 liters and are suitable for small vial lines or bulk material suppliers. They also meet global certification requirements including UL, CE, ASME and CSA.
Key features:
Automatic vacuum laminate sealing: the Food Lyophilization Processprocess is safe and contamination-free.
Fully automated modes, such as wash-in-place (SIP) and clean-in-place (CIP) control: reduces manual intervention and increases efficiency.
Adoption of SCADA control system: comply with cGMP, GAMP5 related regulations.
High-precision shelves: flatness ≤1.0mm, temperature uniformity ≤1℃.
Energy-saving system: Food Lyophilization Process adopts intelligent control of compressor and vacuum pump to reduce energy consumption.
Freeze-dried injectables
Vaccines, hormones, etc.
Biological products
Plasma, diagnostics, biology
Freeze-dried nutrients, food, fruits, etc.
Fruits, bacteria, food supplements, pet food
| Model | LYOPRO-10.0 | LYOPRO-13.0 | LYOPRO-16.0 | LYOPRO-20.0 | LYOPRO-25.0 | LYOPRO-30.0 | LYOPRO-40.0 | LYOPRO-50.0 |
| Drying capacity (Liter) | 200 | 260 | 320 | 400 | 500 | 600 | 800 | 1000 |
| Shelf area(m²) | 9.72 | 12.96 | 15.84 | 19.8 | 24.75 | 30 | 42 | 49.5 |
| Shelf size(L*W)(mm) | 1200*900 | 1200*1200 | 1200*1200 | 1500*1200 | 1500*1500 | 2000*1500 | 2000*1500 | 2200*1500 |
| Useable Shelf No. | 9 | 9 | 11 | 11 | 11 | 10 | 14 | 15 |
| Vial loading quantity φ16 | 40000 | 56000 | 68000 | 80000 | 100000 | 120000 | 175000 | 200000 |
| φ22 | 20000 | 28000 | 34000 | 40000 | 50000 | 60000 | 85000 | 100000 |
| Inter. Shelf distance | 100 | 100 | 100 | 100 | 100 | 100 | 90 | 90 |
| Shelf ultimate cooling temperature(℃) | -55 | -55 | -55 | -55 | -55 | -55 | -55 | -55 |
| Condenser ultimate cooling temperature(℃) | -75 | -75 | -75 | -75 | -75 | -75 | -75 | -75 |
| Ultimate vacuum(Pa) | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 |
| Dimension(L*W*H)(mm) | 6000*1750*3800 | 6800*2000*3800 | 6800*2000*4200 | 7500*2000*4200 | 7200*3000*4200 | 7600*3000*4200 | 7600*3200*4500 | 9600*2300*4700 |
| Weight(Kg) | 10000 | 12500 | 15000 | 17500 | 20000 | 25000 | 30000 | 35000 |
| Power(KW) | 63 | 77.5 | 91.5 | 120 | 135 | 147 | 179 | 215 |
* Sub-door: Located at the front of the chamber. Automated operation.
* CIP (Cleaning in Place) and SIP (Sterilization in Place) systems.
* Computer-based SCADA system; all data can be recorded in tabular or graph format and easily printed for storage.
* Adjustable shelf space mechanism.
* Bottle stopper sub-system.
Advanced technology in freeze dryers.
>>> Energy-saving functions (motor switching, inverter control)
>>> Automatic alarm and email notification to user
>>> Eutectic online determination function
>>> Maintenance precautions
>>> Critical system backup and automatic replacement (compressor, vacuum pump, circulation pump, etc.)
More customer-satisfying services
>>> Preventative maintenance services during the warranty period
>>> AMC service for all machine lifespans
>>> Understanding of all brands of freeze dryer services
>>> Retrofitting services and spare parts
More understanding of oversight in fabrication
>>> Separation of stainless steel from carbon steel inventory
>>> Separate tools for stainless steel and carbon steel
>>> No scratches on SS plates.
>>> No residual water on clean pipes
